High Quality 10 Gigabit Ethernet Optical Fiber Ethernet Switch

Product Categories
H-LIN INTERNATIONAL (HK) LIMITED
Contact Now

High Quality 10 Gigabit Ethernet Optical Fiber Ethernet Switch

  • 1
  • 2

Brand Name : H-LIN

Model Number : HL-7500-24X

Certification : CE/ROHS/FCC

Place of Origin : Shenzhen China

MOQ : 1 Piece/Pieces

Price : negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 2000 Piece/Pieces per Month

Delivery Time : Shipped in 5-8 days after payment

Packaging Details : Original Paper packaging/Export product packaging.

Ports : 24

Transmission Rate : 10/100/1000/10000M

Communication Mode : Full-Duplex & Half-Duplex

Switch Capacity : 480Gbps

power : ≥80W

Temperature : -40-70℃

Size : 442*329*44(mm)

Warranty : 3 Years

Contact Now

Features

1.480g has edge hardware backplane bandwidth routing, wire speed layer three switching packet forwarding rate
of 357.12mpps
2.Can be deployed in the network core, and provides several last 1 km technology of plug and play;
3.It is easy to install and use SFP at the same time, is also backward compatible with XFP;
4.All ports support auto negotiation function (duplex / speed);
5.It supports auto-mdix function, automatic identification through cable and cross network Line;

specification
The product model
HL-7500-24X
Fixed port
24 SFP ports, 1 10M/100M/1000MRJ45 port, 1 Console port management
Backplane bandwidth
480Gbps
Packet forwarding rate
357.12Mpps
Processor
RISC 400MHz
Flash memory capacity
8MB
The memory capacity
256MB
Address table
16K
Product characteristics
Spanning tree
Support STP, RSTP, MSTP Support PVST/PVST+
VLAN
Support port-based VLAN Support MAC-based VLAN Support 802.1Q labeled VLAN Support for Super Vlan Support for Private Vlan Support for the GVRP dynamic VLAN configuration Support QinQ and flexible QinQ Support for Voice VLAN
Flow control
Based on a standard IEEE 802.3x flow control Using IEEE 802.1Qbb priority flow control Support CAR function
Broadcast control
Restraining broadcast storm, stop sending so long as reaching a critical point
Port binding
Each group of a maximum of 8, while support 128 group LACP dynamic or static polymerization
Port mirroring
Support based on flow classification mirroring and port mirroring
Stacked
Stacked 16 hard, soft stacking 32 Using clustering techniques, with a unified centralized management of IP address to do address resource saving
Strategy routing
Support based on IP strategy routing
The proxy function
Support Proxy ARP, DNS Proxy
Redundancy backup
Support for VRRP, HSRP Hot Standby Router Protocol
Characteristics of DHCP
DHCP Server, DHCP Client and support DHCP relay
Function of NAT
Support the static or dynamic NAT address translation function
Physical characteristics
Appearance size
442x329x44mm
Power characteristic
AC 110-240V adaptive, 47-63Hz, 1A/230V, RPS power hot backup
Power
≥80W
Indicator lamp
Power indicator, indication of system, connecting / transceiver instructions
Environment Temperature
0-50 ℃ operation,-40-70 ℃ preservation,0-90% no condensation

Production&Packge

High Quality 10 Gigabit Ethernet Optical Fiber Ethernet Switch
